Approval: CCC, CE, UKCA, cULus Listed, KOSHA, EAC (Eurasian), TÜV
Supply voltage (V): 24-24 V
Type of supply voltage U1: DC
Power consumption DC: 4 W
Number of inputs: 2
Number of semicond. outputs: 1
Utilisation cat. to EN 60947-1: DC-12
Utilisation cat. AC/DC1 stand.: EN 60947-4-1
Voltage AC1 safety cont.:240V
Max. current AC1 safety cont.: 6 A
Voltage DC1 safety cont.: 24 V
Max. current DC1 safety cont.: 6 A
Utilisation cat. AC15/DC13sta.: EN 60947-5-1
Voltage AC15 safety cont.: 230 V
Max. current AC15 safety cont.: 3 A
Voltage DC13 safety cont.: 24 V
Safety contacts: AC at UL: 240 VAC G.U. (same polarity)
Safety contacts: pilot duty: R300, B300
Relay contact material: AgCuNi
Addit. contact details relay: + 0.2 µm Au
Climatic suitability to ...: EN 60068-2-78
Ambient temperature: 10 °C
Humidity rating: 93 % r. h. at 40 °C
Condensation permitted: Not permitted
EMC to standard ...: EN 60947-5-1, EN 61000-6-2, EN 61000-6-4, EN 61326-3-1
Vibration to standard ...: EN 60068-2-6
Clearance & creepage dist. to: EN 60947-1
Overvoltage category: III / II
Pollution degree clear.&creep.: 2
Protection type, housing: IP40
Selectable times: 0.8 s, 0.4 s,,0.2 s, 0.3 s15 s, 1.5 s, 2.5 s, 25 s, 35 s, 0.5 s, 0.6 s, 7 s, 6 s, 3 s, 5 s, 4 s, 210 s, 150 s, 0.1 s, 0.04 s, 8 s, 90 s, 80 s, 60 s, 50 s, 20 s, 40 s, 30 s, 16 s, 1 s, 2 s, 70 s, 0.7000000000000001 s, 100 s, 120 s, 300 s, 200 s, 140 s, 160 s, 3.5 s, 180 s, 14 s, 240 s, 12 s, 10 s
Tolerance TV: +/-1% +/- +/-20 ms
Repetition accuracy: +/-1 % + +/-20 ms
Tolerance in event of error: +/-15 % + +/-20 ms
Max. delay time formula: tv + 15 % + 20 ms
Mounting position: any
Housing material lower section: PC
Housing material front plate: PC
Housing material upper part: PC
Connection terminal: Spring-loaded terminal
Terminal style: plug-in
Height dimension: 100 mm
Width dimension: 22.5 mm
Depth dimension: 120 mm
Net weight: 235 g
Gross weight: 245 g
