Approval: CCC, CE, UKCA, cULus Listed, KOSHA, EAC (Eurasian), TÜV
Supply voltage (V): 24-24 V
Type of supply voltage U1: DC
Power consumption DC: 2.5 W
Number of inputs: 2
DC voltage at input: 24 V DC
Number of semicond. outputs: 1
Utilisation cat. to EN 60947-1: DC-12
Utilisation cat. AC/DC1 stand.: EN 60947-4-1
Voltage AC1 safety cont.:240V
Max. current AC1 safety cont.: 6 A
Voltage DC1 safety cont.: 24 V
Max. current DC1 safety cont.: 6 A
Utilisation cat. AC15/DC13sta.: EN 60947-5-1
Voltage AC15 safety cont.: 230 V
Max. current AC15 safety cont.: 5 A
Voltage DC13 safety cont.: 24 V
Safety contacts: AC at UL: 240 VAC G.U. (same polarity)
Relay contact material: AgCuNi
Addit. contact details relay: + 0.2 µm Au
Climatic suitability to ...: EN 60068-2-78
Ambient temperature: -10 - -10 °C
Humidity rating: 93 % r. h. at 40 °C
Condensation permitted: Not permitted
EMC to standard ...: EN 60947-5-1, EN 61000-6-2, EN 61000-6-4, EN 61326-3-1
Vibration to standard ...: EN 60068-2-6
Clearance & creepage dist. to: EN 60947-1
Overvoltage category: III / II
Pollution degree clear.&creep.: 2
Protection type, housing: IP40
Mounting position: any
Housing material lower section: PC
Housing material front plate: PC
Housing material upper part: PC
Connection terminal: Spring-loaded terminal
Terminal style: plug-in
Height dimension: 100 mm
Width dimension: 17.5 mm
Depth dimension: 120 mm
Net weight: 140 g
Gross weight: 150 g
